DOGE 400
2 UNITS UNDER CONSTRUCTION
HULL
| Hull Type | Full displacement with Bow Bulb |
| Hull | Steel - AH36 |
| Superstructure | Ligh Alloy - 5083/6060 |
MEASUREMENTS
| Length all open | 41,80 m. |
| Length overall | 40,37 m. |
| Length waterline | 35,65 m. |
| Maximum beam | 8,50 m. |
| Draught @ half load* | 2,35 m. |
| Draught @ full load * | 2,40 m. |
| Displacement @ half load* | 305 T |
| Displacement @ full load* | 335 T |
| Gross Tonnage | <500 GT |
ACCOMODATION
| Guest accomodation | 10 people (5 cabins) |
| Crew accomodation | 7 people (4 cabins) |
| Tender lenght inside Garage | 6.25 m. Diesel Jet |
PROPULSION
| Engines |
a) 2x MAN D2868 LE489 V12 RAT.B b) 2 x CAT C32 V12 RAT. B |
| Power output @ 100/ MCR** |
a) 2 x 1450 Hp / 2 x 1066 kW @ 2100 rpm b) 2 x 1450 Hp / 2 x 1066 kW @ 2100 rpm |
| Gearbox |
a) WAF 464 L b) WAF 464 L |
| Propulsion | Direct shaft line with 2 Flexible coupling Vulkan ProFlex |
| Gensets | 2 x 100 kW 50 Hz |
PERFORMANCE
| Maximum speed *** |
a) 16,0 kn b) 16,0 kn |
| Cruising speed *** |
a) 13,0 kn b) 13,0 kn |
| Economical speed *** | 10 Kn |
| Long range speed * | 8 Kn |
| Range @ economical speed 10 Kn (approx) | 5.500 nm |
| Range @ long range speed 8 Kn (approx) | 7.000 nm |
TANK CAPACITIES
| Fuel oil tank capacity | 55.000 lt. |
| Fresh water tank capacity | 15.000 lt. |
| Swimm/pool water tank capacity | 10.000 lt. |
| Black-Grey water tank capacity | 10.000 lt. |
| Urea tank capacity | 3.000 lt. |
| Clean lube oil tank capacity | 1.000 lt. |
| Dirty lube oil tank capacity | 1.000 lt. |
| Bridge tank capacity | 1.250 lt. |
| Overflow tank capacity | 1.350 lt. |
EXTERNAL DESIGN
Design ALOT
INTERNAL DESIGN
MARGINI Architects
ENGINEERING
InNave
SIDE VIEW
TOP VIEW
SUNDECK
OPTIONAL - AUXILIARY PILOT STATION ON UPPER DECK
UPPER DECK
MAIN DECK
LOWER DECK
